Pride Mobility 3-Wire CTS Throttle Potentiometer (ELE123102)
Pride Mobility 3-Wire CTS Throttle Potentiometer (ELE123102)
In stock
Couldn't load pickup availability
- Free ground shipping when you order before 2:00 PM EST (M-F)(Contiguous US Only)
- 30 Day Return Policy
- Fulfillment: Usually ships in 1-2 business days
- This Product Is Backed By A 90-day Limited Warranty Against Manufacturing Defects
Product Description
Genuine OEM replacement 3-Wire CTS Throttle Potentiometer with Downward Bracket (Part Number: ELE123102) for a wide variety of Pride Mobility scooters. It directly replaces and supersedes previous part numbers DWR9983H037, ELEASMB7342, and ELE131375(Read note found below regarding this part).
Description From The Pride Mobility Service Manual: CTS throttle retro-fit with downward bracket
Important Fitment Notes:
- Wire Count: This is a 3-wire throttle with a 3-pin connector. If your original speed pot has 5 wires, this part will NOT replace it.
- Replacing Part ELE131375: If you are replacing the discontinued part number ELE131375, you must visually inspect your throttle lever mounting plate orientation. You will need to order both this throttle (ELE123102) and part DGN120203 to successfully replace ELE131375.
- Manufacturer:
- Pride Mobility (OEM)
- Part Number:
- ELE123102
- Component Type:
- Throttle Potentiometer (Speed Pot)
- Connector Type:
- 3-Pin Connector (3-Wire)
- Replaces / Supersedes:
- DWR9983H037, ELEASMB7342, ELE131375
Equipment Compatibility
- Pride Mobility / Go-Go Scooters:
- Go-Go ES & ES8 (S83 / S84)
- Maxima (SC901 / SC941 / S901 / S941)
- Pathrider ES Series (S104 - AU)
- Pursuit 2 (SC7132 / S7132)
- Victory 9 (SC609 / SC609PS / SC709) - Includes models ending in 1015 & subsequent, and 1022 & subsequent
- Victory 9.2 (S6092 / S7092)
- Victory 10 (SC610 / SC710) - Includes models ending in 1015 & subsequent, and 1022 & subsequent
- Victory 10.2 (S6102 / S7102)
- Victory ES 9 & ES 10 (S93 / S104)
- Victory Platinum (SC710PLA) - For models ending in 1001, 1002, and 1003
- Victory Sport (S710DXW)
- VA Victory 9 (SC609V)
- VA Victory 10 (S610V / S710V) - For models ending in 1001, 1002, 3005, 3006, 3007, 3008, 3009, and 3010
